AV-3010A 15 Inch Touch Screen Surgical Breathing Machine Cart ICU Ventilator Apparatus for Adult Pediatric Neonatal
1 / 1
AV-3010A 15 Inch Touch Screen Surgical Breathing Machine Cart ICU Ventilator Apparatus for Adult Pediatric Neonatal

AV-3010A 15 Inch Touch Screen Surgical Breathing Machine Cart ICU Ventilator Apparatus for Adult Pediatric Neonatal

Customization: Available
Customized: Customized
Certification: CE
Send Inquiry

Product Description

Basic Product Information
Model NO.AV-3010A
ScaleMedium
TypeBreathing Apparatus
Power AlarmAvailable
CertificatesISO, CE
SourceOxygen
Screen15 Inch Touch Screen
Production Capacity500 Sets/Month
Product Overview & Features

AV-3010A 15 Inch Touch Screen Surgical Breathing Machine ICU Ventilator

ICU Ventilator Apparatus
  • Removable 15 inch large touch screen
  • Day and night mode change
  • Applied for adult, pediatric and infant
  • Separated non-invasive module with leakage compensation
  • Automatic alarm setting adjusting
  • Pre-set ideal weight calculation
  • Assistant Nebulization treatment / O2 remedy
  • Multi-mode: VCV, SIMV, PSV, PCV, CPAP, APNEA, BIPAP, APRV, PA-VC, SIGH
  • Advanced air compressor for stable input
  • Self testing and automatic calibration
  • Comprehensive trends record and event log
  • Auto-wash for exhaust valve
Technical Specifications
Technique Specifications
Physical Specifications
Dimensions45″ x 55″ x 140cm
Weight65kg
Display15 inch Colour LCD Touch Screen (Day/Night Mode)
GraphicsWaveforms of P-T, F-T, V-T; Loops P-V, F-V
Ventilator Parameters
Tidal Volume Range10-2000ml
Pressure Range5-80 cmH2O
Respiration Rate1-150 bpm (1-40 bpm under SIMV)
Oxygen Concentration21% - 100%
PEEP TypeIntegrated, Electronic Control (0-40 cmH2O)
Power & Environmental
Battery PowerLead-acid 12V, 4Ah (Typical 120 mins run-time)
Air CompressorAC 220V±10%, 50Hz, Noise ≤50dB
Operating Temp5 °C ~ 40 °C
Ventilator Display and Interface
System Gallery
Production Detail 1
Production Detail 2
Frequently Asked Questions
Q1: Which patient groups is the AV-3010A suitable for? A1: This ICU ventilator is highly versatile and can be used for adult, pediatric, and neonatal/infant patients.
Q2: Does the device support non-invasive ventilation? A2: Yes, it features a professional separated non-invasive module and supports leakage compensation for effective treatment.
Q3: How long can the battery operate in case of power failure? A3: The integrated 12V lead-acid battery provides approximately 120 minutes of typical run-time.
Q4: What are the main ventilation modes available? A4: It supports a wide range of modes including VCV, V-SIMV, P-SIMV, PSV, PCV, CPAP, APNEA, BIPAP, APRV, and PA-VC.
Q5: Is the screen user-friendly for hospital environments? A5: Yes, it features a large 15-inch removable touch screen with a day/night mode to adapt to different lighting conditions in the ICU.
Q6: What graphics can be monitored on the display? A6: The system displays real-time waveforms for Pressure-Time (P-T), Flow-Time (F-T), and Volume-Time (V-T), as well as P-V and F-V loops.
